Elevator Load Sensor

NV68-P-F

	Rated load	1000/3000kg	Safe overload	150% F.S
	Sensitivity	2.0±0.02% mV/V	Ultimate overload	200% F.S
	Total error	±0.5% F.S	Excitation	5~12V DC
	Creep error	±0.02% F.S	Max.excitation	15V DC
	TC SPAN	±0.02% F.S/10℃	Insulation impedance	≥5000M Ω
	Working temperature	-30℃~+70℃	Protection class	IP67/IP68
	Input impedance	760±10 Ω	Construction	Alloy Steel
	Output impedance	700±2 Ω	Cable length	5m

NV68-P-E

	Rated load	1000 / 3000 / 5000KG	Safe Overload	150% F.S
	Sensitivity	2.0±0.02% mV / V	Ultimate Overload	200% F.S
	Total error	±0.5% F.S	Excitation	5~12V DC
	Creep error	±0.02% F.S	Max.excitation	15V DC
	TC SPAN	±0.02% F.S / 10℃	Insulation Impedance	≥5000M Ω
	Working Temperature	-30℃~+70℃	Protection Class	IP67/IP68
	Input Impedance	760±10 Ω	Construction	Alloy Steel
	Output Impedance	700±2 Ω	Cable Length	5m

NV68-H-M

	Rated Load	500 / 1000 / 3000KG	Safe Overload	150% F.S
	Sensitivity	2.0±0.02% mV / V	Ultimate Overload	200% F.S
	Total Error	±0.5% F.S	Excitation	5~12V DC
	Creep Error	±0.02% F.S	Max.excitation	15V DC
	TC SPAN	±0.02% F.S / 10℃	Insulation Impedance	≥5000M Ω
	Working Temperature	-30℃~+70℃	Protection Class	IP67 / IP68
	Input Impedance	380±20 Ω	Construction	Alloy Steel
	Output Impedance	352±3 Ω	Cable Length	1.8m

NV68-S-560

	Power supply voltage	AC/DC16~65V	Temperature Range	-40~75℃
	Power rating	≤4W	Measuring Channel	2
	Alarm relays	5	Bandwidth	30Hz
	Max. switching voltage	380VAC	Sampling rate	100Hz
	Max. peak current	16A	Internal Resolution Points	±32000
	Rated current	8A	Acoustic, optic, electric alarm	Enable
	Rated load (resistive) in AC1	2500VA	Delayed alarm	Enable
	Rated load (inductive) in AC15	800VA	High compensation	Enable

NV68-MR100

	Operating Voltage	AC/DC16~48V	Rated load	3000Kg
	Nominal Power	≤4W	Safe overload	150%
	Relay Number	1(overload)	Ultimate overload	200%
	Contact load	8A 250VAC	Measuring precision	0.01%
	Display type	4 digits 0.36inch LED	Operating temperature	-45℃-+85℃
	Display mode	weight/percentage	Size	98×84×58mm3
	Reasonable rope number	1	Cable length	1m
	Rope diameter	8-16mm	Protection class	IP65

NV68-MR200

	Power supply voltage	AC/DC16-65V	Analog output(optional)
	Power rating	≤4W	Galvanically isolated	Ο
	Alarm relays	3	Hold input	12V-230V AC/DC
	Max. switching voltage	250VAC	Rope diameter	4mm-16mm
	Max. peak current	5A	Measuring range	300kg-2500kg
	Rated current	3A	Maximum load	5000kg
	Rated load (resistive) in AC1	800VA	Dimensions	210mm×230mm×130mm
	Rated load (inductive) in AC15	200VA	Length of cable set	3m(standard)

NV68-MR300

	Power supply voltage	AC/DC16-65V	Analog output(optional)
	Power rating	≤4W	Galvanically isolated	Ο
	Alarm relays	3	Hold input	12V-230V AC/DC
	Max. switching voltage	250VAC	Rope diameter	4mm-16mm
	Max. peak current	5A	Measuring range	1000kg-5000kg
	Rated current	3A	Maximum load	10000kg
	Rated load (resistive) in AC1	800VA	Dimensions	306mm×230mm×130mm
	Rated load (inductive) in AC15	200VA	Length of cable set	3m(standard)
